Official Supplier Horizontal Pressure Steam Sterilizer Scitek ST-HYDA Series Autoclave Horizontal Ekonomis Laboratorium
Deskripsi Produk
Scitek ST-HYDA Series adalah Horizontal Pressure Steam Sterilizer (autoclave horizontal ekonomis) kelas profesional yang dirancang khusus untuk memproses sterilisasi instrumen bervolume besar di laboratorium, klinik, pusat penelitian, serta industri pengolahan makanan. Memanfaatkan metode pertukaran gravitasi (gravity displacement exchange) untuk mengeluarkan udara dingin dari dalam chamber secara menyeluruh, alat ini menjamin penetrasi uap jenuh yang andal dan konisten. Proses sterilisasi berjalan secara otomatis penuh di bawah kendali sistem mikrokomputer yang secara mandiri mengatur laju masuk dan keluarnya uap berdasarkan sensor suhu ruang. Mengutamakan aspek keselamatan kerja K3, unit ini dibekali fitur keamanan berlapis seperti interlock pintu berbasis tekanan mekanis (pintu tidak dapat dibuka jika tekanan internal di atas 0.027MPa), katup pengaman tekanan berlebih (safety valve aktif otomatis jika tekanan melebihi 0.24MPa), pemutus daya anti-dry burning saat kekurangan air, serta fungsi pengeringan pakaian medis (dressing drying function) yang terintegrasi.
Spesifikasi Teknis
| Brand | Scitek |
|---|---|
| Model | ST-H150YDA / ST-H200YDA / ST-H280YDA / ST-H400YDA / ST-H500YDA |
| Chamber Capacity | 150 Liters / 200 Liters / 280 Liters / 400 Liters / 500 Liters |
| Chamber Size (Diameter×Depth) | 440 mm × 1000 mm / 515 mm × 1000 mm / 600 mm × 1000 mm / 700 mm × 1100 mm / 700 mm × 1300 mm |
| Control System | Automatically controlled sterilization process with intuitive knobs, indicator lights, and integrated water level meter |
| Air Elimination Method | High-efficiency gravity displacement exchange mechanism |
| Drying Function | Integrated drying system specialized for medical dressing and textile drying (0 to 60 minutes) |
| Sterilization Parameters | Temperature range from 40 to 134 derajat Celsius (Maximum working temperature 134 derajat Celsius with uniformity within ±2 derajat Celsius) |
| Working Pressure | 0.22 MPa (Safety valve auto-exhaust at 0.24 MPa) |
| Sterilization Time Range | Adjustable from 0 to 60 minutes |
| Safety Protection System | Over-temperature auto-protect, over-pressure self-discharge safety valve, low-water level automatic power cutoff with audio-visual alarm, and strict door pressure interlock safety device |
| Chamber Material | High-grade heavy-duty polished stainless steel with internal multi-tier shelves |
| Power Supply and Consumption | 9 kW (150L/200L) / 12 kW (280L) / 18 kW (400L/500L), AC 380V / 50Hz (Three-phase high-power configuration) |
| Application | Large-scale surgical instruments sterilization, bulk medical dressing drying, laboratory glassware disinfection, industrial quality control, and culture media preparation controls |
