Official Supplier Horizontal Pulse Vacuum Autoclave Scitek ST-HPL Series Sterilisator Horizontal Pintu Geser Otomatis Pass-Through
Deskripsi Produk
Scitek ST-HPL Series (Liftgate/Sliding Door) adalah Horizontal Pulse Vacuum Autoclave (sterilisator horizontal vakum pulsasi) kelas industri tingkat lanjut yang dirancang khusus untuk memenuhi standar sterilisasi tertinggi di CSSD rumah sakit besar, laboratorium biosafety (BSL-3/BSL-4), dan industri manufaktur farmasi. Mengadopsi mekanisme pintu lift geser vertikal otomatis (motorized vertical sliding door) yang hemat ruang, autoclave ini tersedia dalam konfigurasi pintu tunggal maupun pintu ganda (double-door pass-through system) untuk memisahkan area bersih dan area kontaminasi secara ketat demi mencegah kontaminasi silang. Didukung oleh pompa vakum cincin air yang kuat, alat ini menerapkan metode pre-vacuum pulsasi berulang untuk memastikan eliminasi udara dingin secara menyeluruh dari dalam chamber persegi panjang stainless steel berkualitas tinggi. Seluruh siklus operasional dikendalikan penuh oleh PLC mikrokomputer berbasis layar sentuh warna yang canggih, lengkap dengan jaket pemanas (jacket heating) dan pengeringan vakum mendalam guna menghasilkan muatan yang kering sempurna sekaligus menjamin keselamatan kerja K3 yang optimal.
Spesifikasi Teknis
| Brand | Scitek |
|---|---|
| Model | ST-HPL150 / ST-HPL250 / ST-HPL360 / ST-HPL600 / ST-HPL800 / ST-HPL1200 / ST-HPL1500 |
| Chamber Capacity | 150 Liters / 250 Liters / 360 Liters / 600 Liters / 800 Liters / 1200 Liters / 1500 Liters |
| Chamber Configuration | Horizontal heavy-duty rectangular structure |
| Door Mechanism | Motorized automatic vertical sliding lift door (Single door or double-door pass-through option available) |
| Air Elimination Method | High-performance multi-stage pulsating pre-vacuum system with an integrated water-ring vacuum pump |
| Drying Performance | Advanced steam jacket heating and deep vacuum drying system post-sterilization cycle |
| Control Interface | Programmable Logic Controller (PLC) with human-machine interface color touch screen display |
| Standard Test Cycles | Pre-programmed Bowie-Dick (B&D) test, Helix test, and Vacuum leak test programs |
| Data Logging & Documentation | Integrated thermal printer and communication ports for digital monitoring and compliance tracking |
| Safety Protection System | Over-temperature protection, over-pressure mechanical safety valve, strict dual-door interlocking safety (for pass-through models), anti-dry burning, and automated emergency stop controls |
| Chamber Material | Premium-grade corrosion-resistant stainless steel (SUS316L for inner chamber, SUS304 for jacket/housing) |
| Power Supply | AC 380V / 50Hz (Three-phase high-power configuration for heavy-duty industrial steam generation) |
| Application | Central Sterile Supply Department (CSSD) bulk processing, large-scale pharmaceutical manufacturing sterilization, biosafety laboratory barrier wall installations, and high-volume medical device autoclaving procedures |
