Official Supplier Portable Autoclave with Electric/Gas Heating Scitek ST-PB Series Sterilisator Portabel Pemanas Ganda Listrik dan Gas 18L 24L
Deskripsi Produk
Scitek ST-PB Series adalah Portable Autoclave dengan sistem pemanas ganda (dual heating options: electric and gas) yang dirancang fleksibel untuk kebutuhan sterilisasi umum secara cepat dan efisien menggunakan uap jenuh bertekanan. Keunggulan utama seri ini terletak pada kemampuannya untuk dioperasikan menggunakan energi listrik maupun kompor gas eksternal, menjadikannya solusi andal untuk daerah terpencil, laboratorium lapangan, pos kesehatan darurat, maupun wilayah dengan pasokan listrik yang tidak stabil. Selain untuk sterilisasi instrumen medis dan laboratorium, alat ini juga dapat difungsikan sebagai wadah pencerna (digester) di dataran tinggi atau pabrik pengolahan air minum. Dibangun dengan konstruksi baja tahan karat (high-quality stainless steel) mengilap yang kokoh, unit ini dilengkapi mekanisme sekrup pengencang (screwing structure), segel mandiri elastis (self-inflating seal), pengukur tekanan skala ganda (double-scale pressure gauge), serta katup pembuangan otomatis (automatic pressure release) demi menjamin aspek keselamatan K3 yang optimal.
Spesifikasi Teknis
| Brand | Scitek |
|---|---|
| Model | ST-P18B / ST-P24B |
| Chamber Capacity | 18 Liters / 24 Liters |
| Chamber Dimensions (Diameter×Height) | Ø280 mm × 295 mm (ST-P18B) / Ø280 mm × 390 mm (ST-P24B) |
| Heating Infrastructure | Dual-source energy integration supporting both electric heating elements and external gas burner deployment |
| Structural Material | High-grade polished corrosion-resistant stainless steel for heavy-duty operational life and simplified decontamination |
| Lid Closure System | Robust manual multi-screw wing-nut tightening mechanism combined with a high-durability self-inflating elastomer steam seal |
| Pressure Monitoring System | Integrated precision mechanical double-scale pressure gauge for real-time visual tracking of concurrent chamber temperature and pressure |
| Operational Cycle Parameters | Rated working temperature fixed at 126 derajat Celsius with an automated sterilization cycle efficiency capable of delivering results within an 18-minute holding configuration |
| Working Temperature Accuracy | ±1 derajat Celsius precision control stability |
| Working Pressure Parameters | Rated operational steam pressure capacity at 0.142 MPa |
| Safety Mitigation System | Built-in safety relief valve with automatic overpressure release threshold mechanism |
| Internal Load Configurations | Complete with a high-grade stainless steel internal liner and structural sterilization basket for secure tool positioning |
| Power Connection & Consumption | 2.0 kW element, AC 220V / 50Hz single-phase configuration (active during electric mode operation) |
| Application | Off-grid clinical tool sterilization, rural community water plant digestions, remote field research laboratories, and dual-fuel backup institutional medical autoclaving controls |
