Official Supplier Vertical Pressure Steam Sterilizer Scitek ST-VG Series Autoclave Layar Sentuh dengan Mobile Probe dan Printer
Deskripsi Produk
Scitek ST-VG Series adalah Vertical Pressure Steam Sterilizer (autoclave vertikal) kelas premium cerdas yang dikembangkan untuk akurasi sterilisasi tingkat tinggi pada industri farmasi, fasilitas bioteknologi, laboratorium riset, dan rumah sakit. Dilengkapi dengan layar sentuh berwarna (5-inch color touch screen), alat ini memberikan kemudahan visualisasi data dan pengaturan parameter operasional secara interaktif. Keunggulan utama seri ST-VG terletak pada integrasi mobile probe (sensor suhu portabel tambahan) yang dapat dicelupkan langsung ke dalam sampel cairan atau media kultur untuk pembacaan suhu internal yang presisi. Ditunjang tangki air terintegrasi (built-in water tank), unit ini mampu melakukan pengisian air otomatis serta sirkulasi uap internal yang dilengkapi exhaust cooling system guna mendinginkan uap, mencegah timbulnya aerosol berbahaya, dan menjaga udara sekitar tetap bersih, kering, serta steril sesuai regulasi K3.
Spesifikasi Teknis
| Brand | Scitek |
|---|---|
| Model | ST-VGA50 / ST-VGA80 / ST-VGA100 / ST-VG50 / ST-VG80 / ST-VG100 / ST-VG120 |
| Chamber Capacity | 60 Liters (VG50/VGA50) / 80 Liters (VG80/VGA80) / 100 Liters (VG100/VGA100) / 120 Liters (VG120) |
| Chamber Size (Diameter×H) | 386 mm × 515 mm / 386 mm × 695 mm / 386 mm × 875 mm / 386 mm × 1054 mm |
| Control Interface | 5-inch color touch screen microcomputer control system |
| Advanced Sensors | Integrated built-in mobile probe for direct liquid/culture media core temperature measurement |
| Water and Steam Circulation | Built-in water tank with automatic water replenishment and internal steam-water circulation |
| Exhaust System | High-efficiency exhaust cooling system to prevent aerosol generation and external steam emission |
| Data Documentation | Equipped with a standard built-in configuration printer and USB communication socket |
| Sterilization Temperature Range | 121 to 134 derajat Celsius (Temperature accuracy up to 0.5 derajat Celsius) |
| Pressure Parameters | Highest working pressure at 0.25 Mpa (Design pressure range 0.28 to 0.3 Mpa) |
| Safety System | Water cut-off protection control, safety door interlock, over-temperature cutoff, and over-pressure dual automatic protection |
| Chamber Material | Corrosion-resistant premium-grade stainless steel with heavy-duty metal handwheel and power switches |
| Power Supply | AC 220V ± 22V / 50Hz ± 1Hz |
| Application | Liquid agar culture media sterilization, aerosol-free biohazard waste treatment, pharmaceutical raw material disinfection, and clinical laboratory autoclaving controls |
